product model | TX08S | TX10S | TX12S | TX08E | TX10E | TX12E | TX08Q | TX10E | TX12E | ||||||
heating method | steam heating | electrical heating | bsqz | ||||||||||||
capacitykg | 8+8 | 10+10 | 12+12 | 8+8 | 10+10 | 12+12 | 8+8 | 10+10 | 12+12 | ||||||
Washing drum sizemm | 580*310 | 580*380 | 580*450 | 580*310 | 580*380 | 580*450 | 580*310 | 580*380 | 580*450 | ||||||
Washing Speed r/min | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | 45 | ||||||
Dehydration rater/min | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | ||||||
Washer-extractor motor powerkw | 0.75 | 1.1 | 1.5 | 0.75 | 1.1 | 1.5 | 0.75 | 1.1 | 1.5 | ||||||
steam consumptionkg | 12 | 15 | 18 | / | / | / | / | / | / | ||||||
heating powerkw | / | / | / | 7.5 | 9 | 12 | / | / | / | ||||||
Size of drying drum mm | 700*350 | 700*400 | 700*480 | 700*350 | 700*400 | 700*480 | 700*350 | 700*400 | 700*480 | ||||||
Drying heating power kw | / | / | / | 8 | 10 | 12 | / | / | / | ||||||
Dryer motor power kw | 0.59 | 0.59 | 0.62 | 0.59 | 0.59 | 0.62 | 0.59 | 0.59 | 0.62 | ||||||
Gas consumption Kg/batch | / | / | / | / | / | / | 0.85 | 1.05 | 1.25 | ||||||
size mm | 910*1000*2000 | 910*1120*2000 | 910*1200*2000 | 910*1000*2000 | 910*1120*2000 | 910*1200*2000 | 910*1000*2000 | 910*1120*2000 | 910*1200*2000 | ||||||
weight kg | 390 | 460 | 550 | 390 | 460 | 550 | 390 | 460 | 550 |
